    40 Channel LC/APC 100GHz Duplex Athermal AWG DWDM Module GEZHI-DWDM - MUX/DEMUX

    Ask Lasest Price
    Brand Name : Gezhi or OEM
    Model Number : GEZHI-DWDM - MUX/DEMUX
    Certification : CE RoHS,ISO9001
    Price : USD >= 1 pieces $195
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Piece/Pieces per Day
    Delivery Time : 7 Days
    • Product Details
    • Company Profile

    40 Channel LC/APC 100GHz Duplex Athermal AWG DWDM Module GEZHI-DWDM - MUX/DEMUX

    Product description

    40 Channel LC/APC 100GHz Duplex Athermal AWG DWDM Module GEZHI-DWDMMUX/DEMUX

    The AAWG DWDM (Athermal Arrayed Waveguide Grating Dense Wavelength Division Multiplexing) module is a fully passive WDMs based on silica-on-silicon planar technology that requires no electrical power and software. It operates at 50GHz or 100GHz channel spacing ITU Grid DWDM wavelengths from1526nmto 1565nm. The AAWG DWDM can be used to replace the filter-type DWDM Mux DeMux for cases wherenopower is available. The low cost and high performance make it the ideal solution for metro and long-haul DWDM applications. GEZHI Photonics provides a series of customized AAWG DWDM within standard metal box or rack mount to meet different requirements on Port Configuration (32 to 96 channels, 1310nm/monitoringportsavailable), Operating Wavelength, Fiber Type, Fiber Length, Input Connector, and Output Connector. And GEZHI Photonics provide Gaussian and Flat Top type chips of DWDM AAWG, which customers can choose accoding to their actual needs.

    Feature


    Low Insertion Loss High Isolation

    Low PDL Compact Design

    Good channel-to-channel uniformity

    Wide Operating Wavelength From 1260nm to 1620nm Wide Operating Temperature From -40°C to 85°C High Reliability and Stabilit


    Parameters
    Channel Space (GHz)
    100
    200
    Channel Number
    1x4
    1x8
    1x16
    1x4
    1x8
    1x16
    Center Wavelength (nm)
    ITU Grid
    Center Wavelength Accuracy (nm)
    ±0.05
    ±0.1
    Channel Passband (@-0.5dB) (nm)
    0.22
    0.5
    Fiber Type
    SMF-28e with 900um loose tube or customer specified
    IL (dB)
    1.8
    3
    4
    1.7
    2.9
    3.8
    Passband Ripple (dB)
    0.35
    0.4
    0.5
    0.35
    0.4
    0.5
    Isolation (dB)
    Adjacent Channel
    25
    28
    Non-Adjacent Channel
    40
    PDL (dB)
    0.2
    PMD (ps)
    0.1
    RL (dB)
    45
    Directivity (dB)
    50
    Maximum Optical Power (mw)
    300
    Operating Temperature (°C)
    -40~85
    Storage Temperature (°C)
    -40~85
    BOX Package (mm)
    100x80x10 or 140x115x18
    LGX Package
    1U,2U
    19"1 Rack mount Package
    1U

    High Quality & Stability Material

    Use Import Filter with High Reliable & Stable quality

    Use Original EMI OPTOCAST 3410-VM Glue

    Use High Quality G-Lens and Collimator
    Test Enviroment
    NO-dust workshop
    High Temp. Ageing & High-Low Temperature cycling
    100% Testing Before Shipment
    Optical Spectrum Analysis

    FAQ
    Q1:Can I have a sample order? What is your MOQ?
    A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
    Q2: What's the Lead time?
    A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
    Q3: What are the payment terms?
    A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.
    Q4: What is your warranty time
    A4: 1 years' warranty.
    Q5: Could I use our own logo, label and package?
    A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
