SM/MM 1x16 1x32 MEMS Optical Switch Module for PON Network

SM/MM 1x16 1x32 MEMS Optical Switch Module for PON Network

Product Description

MEMS 1X16 1x32 Fiber Optical Switch is a compact, single mode or multimode fiber optical switch configurable for port counts up to 1x64.It utilizes the proprietary microelectromechanical system (MEMS) technology to achieve reliable optical performance and excellent durability; This MEMS optical switch is available in any 1XN size up to 1x64.

SM/MM 1x16 1x32 MEMS Optical Switch Module for PON Network

Features

Compact Structure
Fast Switching Time
Low Insertion Loss
High Reliability

Applications

PON Network
Protection
Instrumentation
Network Monitoring

Specifications

Parameter	Single Mode
Wavelength range (nm)	1240~1640
Insertion loss (dB)	≤2.0 (Typ 1.3)
Crosstalk (dB)	≥ 60 (Typ 75)
Backreflection (dB)	≥ 45 (Typ 55)
Polarisation Dependent Loss (dB)	≤0.15
Repeatability¹ (dB)	≤0.002
Switch time (ms)	≤1 (Typ 0.5)
Switching Voltage ( V )	≤5
Fiber Pigtail (µm)	9/125/900
Durability (cycles)	no wear out
Power Consumption (mW)	≤190
Operation temperature(℃)	0~70
Storage temperature (℃)	-40~85
Package Size (L x W x H) (mm)	175 x 105 x 10

Parameter	Multi-Mode
Wavelength range (nm)	600~1700
Insertion loss (dB)	≤2.0 (Typ 1.5)
Crosstalk (dB)	≥ 45 (Typ 55)
Backreflection (dB)	≥ 35 (Typ 45)
Polarisation Dependent Loss (dB)	≤0.3
Switch time (ms)	≤20 (Typ 2)
Switching Voltage ( V )	≤5
Fiber Pigtail (µm)	50/125/900 or 62.5/125/900
Durability (cycles)	no wear out
Power Consumption (mW)	≤150(Typ 75)
Operation temperature(℃)	0~70
Storage temperature (℃)	-40~85
Package Size (L x W x H) (mm)	175 x 105 x 10

Ordering Information

A	B	C	D	E	F
Type	Wavelength	Fiber Length (m)	Fibre type	Fiber diameter	Connector
1x16 1x32 Specify Custom	1=850nm 2=1310nm 3=1490nm 4=1550nm 5=1625nm 6=1310/1550nm 7=850/1310nm S=Specify Custom	0.5=0.5m 1.0=1.0m 1.5=1.5m S=Specify Custom	9=SMF28,9/125 50=MM 50/125 62=MM 62.5/125 S=Specify Custom	1=250um bare fibre 2=900um loose tube 3=2.0mm loose tube S=Specify Custom	OO=None FP=FC/PC FA=FC/APC SP=SC/PC SA=SC/APC SP=ST/PC SA=ST/APC LP=LC/PC LA=LC/APC X=Others
