High Isolation 1064nm Mini In-line Size Fiber Optic Polarizer PM Fiber Out

Product Description

1064nm Mini Size In-line Polarizer

The In-line Polarizer is designed to pass light with one specific polarization while blocking the other polarization. It can be used to convert unpolarized light into polarized light with high extinction ratio. It can also be used to enhance the extinction ratio of signals with its excellent polarization properties. It is ideal for high speed communication systems and test instrumentations where high polarization extinction ratio is required.

Features	Applications
Low Insertion Loss	Communication Systems
High Return Loss	Test Instrument
High Extinction Ratio	Fiber Sensor
High Reliability	Research
High Stability

Specifications

Center Wavelength	nm	1064
Operating Wavelength Range	nm	±30
Typ. Insertion Loss at 23℃	dB	0.4
Max. Insertion Loss at 23℃	dB	0.6
Min. Return Loss at 23℃	dB	50
Typ. Extinction Ratio at 23℃	dB	30
Min. Extinction Ratio at 23℃	dB	28
Fiber Type for Input & Output	/	SM→SM or SM→PM or PM→PM
Max. Optical Power (CW)	mW	300
Package Dimension	mm	φ3.0x30 or φ3.2x30
Max. Tensile Load	N	5
Operating Temperature	℃	-5~+70
Storage Temperature	℃	-40~+85
With connector, IL is 0.3dB higher, RL is 5dB lower, and ER is 2dB lower.
Connector key is aligned to slow axis.

Package Dimensions

Ordering Information

MILP-1111-23-444-555-67-8-9A
1111 - Wavelength:	1064=1064nm, SSSS=Specified
2 - Fiber Type Option:	1=SM→SM, 2=SM→PM, 3=PM→PM
3 - Working Axis:	F=Fast axis blocked, N=Non-PM
444 - Fiber Type for Input:	003=PM980, 004=Hi1060, SSS=Specified
555 - Fiber Type for Output:	003=PM980, 004=Hi1060, SSS=Specified
6 - Package Dimension:	0=φ3.0x30mm, 1=φ3.2x30mm
7 - Pigtail Type:	0=bare fiber, 1=900μm loose tube
8 - Fiber Length:	0.8=0.8m, 1.0=1m, S=Specified
9 - Connector Type for Input:	0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, N=None, S=Specified
A - Connector Type for Output:	0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, N=None, S=Specified
