Multimode Wideband Fiber Patch Cable 2m LC To FC
Coated Fiber Optic Patch Cord, 1m Fiber Optic Patch Cord, Duplex
Armored Fiber Patch Cord
Tested to TIA and IEC performance specifications3M Volition VF-45
Patch Cords use the excellent reliability and ruggedness of 3M
glass/glass/polymer (GGP) fiber optic cable which is ideal for
applications requiring tight bends, durability and dependability.
The cable used to make Volition patch cords is grade index
multimode optical fiber with 10um glass cladding diameter and 125um
polymer coating diameter. The polymer is a tough permanent coating,
which provides improved strength and bends resistance. The static
fatigue parameter is a 50% improvement over standard life. This
High strength fiber is fully compatible and intermatable with
standard glass fiber.VF-45 Fiber Optic Patch Cord is designed by 3M
and features plug and jack design without the need to adapters.
VF-45 plug is inserted into the socket (jack) at a 45-degree angle,
pressing a pair of fibers into V-grooves inside the socket. This
design of VF-45 Connector eliminates the need for expensive
ferrules thus reduce connector costs.
Features VF-45 Connector is half the size of the SC Connector VF-45 Optical Connector works on standard 62.5µm or 50µm multimode
fiber
Minimum space required when mounted in telecom enclosure or other
racks RJ-45 style latch for ease of use and familiarity
RoHS compliant for all VF-45 connector material | Applications Interconnect socket (field terminated)
Wall outlets and faceplates
Termination and cleaning kits
Test equipment |
Specification
| Item | Parameter |
| Single-mode | Multi-mode |
| Insertion Loss | ≤0.75dB |
| Return Loss | ≥50 dB (SM PC),≥35 dB (MM PC) |
| Repeatability | ≤0.1dB |
| Durability | 0.2dB Max. 1000 mattings |
| Operating Temperature | -40℃~+85℃ |
| Storage Temperature | -40℃~+85℃ |
Quality Control
Our Certificate
Packing & Shipping
AFQ
Q1:Can I have a sample order? What is your MOQ?
A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
Q2: What are the payment terms?
A2: Payment term: T/T, Paypal, Western union,cash payment, Alibaba etc.
Q3: What's the Lead time?
A3: The normal lead time is about 1week, For big quantity and special products. Please check lead time with
our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q4: What is your warranty time
A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your
requirements, design products label, logo, PN, SN, package.
