Singlemode 1xx8t Mechanical Optical Switch LC/UPC connector optical switch

Ask Lasest Price
Brand Name :	GEZHI or OEM
Model Number :	1x8T Optical Switch
Certification :	CE RoHS,ISO9001
Price :	Negotiable
Payment Terms :	T/T, Western Union
Supply Ability :	100000Channel per month
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

Singlemode 1xx8t Mechanical Optical Switch LC/UPC connector optical switch

Optical Route

Product packaging

Finished Item

Inner Package

Carton

Specifications

Mini 1×8 T Type Switch	Unit	Typical
Operation Wavelength	nm	850nm or 1260~1650nm
Insertion Loss	dB	<1.0(MM), <1.2(SM)
Wavelength Dependent Loss	dB	<0.25(MM), <0.30(SM)
Polarization Dependent Loss	dB	<0.1
Return Loss	dB	MM:>35, SM: >55
Cross Talk	dB	MM:>40, SM: >55
Switching Time	ms	Typical: 4 Max:10
Repeatability	dB	<±0.02
Durability	Cycles	>10 Million
Switching Type		Latching / Non-Latching
Optical Power Handling	mW	<500mW
Operating Voltage	VDC	3V or 5V
Operating Temperature	℃	0~+70
Storage Temperature	℃	-40~+85
Fiber Type	/	SM/MM Fiber
Package Dimension	mm	35L x 35W x 9H

Product Overview

Singlemode 1xx8t Mechanical Optical Switch LC/UPC connector optical switch

1x8T Optical Switch

GEZHI Photonics' Mini 1×8 T type Mechanical Fiber Optic Switch (1×8 Optical Switch) support all wavelength at 1260nm~1650nm or 850nm Multimode wavelength, it offers ultra-high reliability, low insertion loss, fast switching speed as well as bi-directional performance. The optical switches are widely used for Optical Network, Protection, Transmitter and Receiver Protection,Network Test System and Instrumentations.

Features

Compact design, Miniature size

Short switching time

Bi-directionalLow optical distortions

Low cross talk, Low Insertion Loss

Wide operating wavelength Range

Applications

R&D in Laboratory

System monitoring

Metropolitan Area Network

Network protection and restoration

Instrumentation, testing, and measurement

Singlemode 1xx8t Mechanical Optical Switch LC/UPC connector optical switch
