    FTTH 1x32 fiber optic switch with rackmount

    Ask Lasest Price
    Brand Name : GEZHI or OEM
    Model Number : 1x32 Optical Switch
    Certification : CE RoHS,ISO9001
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100000Channel per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    FTTH 1x32 fiber optic switch with rackmount


    Product Package

    Finished ItemInner PackageCarton

    Similar Products

    1x2 optical switch1x4T optical switch1x1 optical switch

    Product Overview


    FTTH 1x32 fiber optic switch with rackmount


    1x32 Desktop Optical Switches Rackmount


    1×N rack-mounted optical switch is used for selecting and controlling optic path. It has an important role in the optical communication and applies to multipoint monitoring of optical transmission system, LAN light source/detector auto exchange and optical sensor monitoring system. It also can be used for optic fiber, optical passive components, optical network and cable testing.


    .


    Specifications

    Parameter
    Unit
    OSW-1x32-U
    Wavelength Range
    nm
    850±40/1300±40
    1260~1650
    Operating Wavelength
    nm
    850/1300
    1310/1550
    Insertion Loss
    dB
    Typ. ≤0.8dB, Max.≤1.5 dB
    Typ. ≤0.8dB,Max.≤1.5 dB
    Return Loss
    dB
    MM≥35 SM≥50
    Crosstalk
    dB
    MM≥50 SM≥70
    Polarization Dependent Loss
    dB
    0.05
    WDL
    dB
    ≤0.25
    TDL
    dB
    ≤0.25
    Repeatability
    dB
    ≤±0.02
    Power Supply
    V
    AC:100~ 240 (50/60Hz)
    Lifetime
    times
    ≥107
    Switch Time
    ms
    ≤10
    Optical Power
    mW
    ≤500
    Operating Temperature
    -10~+60
    Storage Temperature
    -40~+85
    Dimension
    mm
    1U:483 x 230 x 45

    Features


    Low insertion loss, Fast switching


    SerialNet, High Reliability, High Stability

    LED display panel. Visual display

    Transparent transmission signal
    RS232 Control & RJ45 Ethernet Remote Management
