    Optical switch 1x8 Optical Switches Single mode 1310/1550nm

    Ask Lasest Price
    Brand Name : GEZHI or OEM
    Model Number : 1x8 Optical Switch
    Certification : CE RoHS,ISO9001
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100000Channel per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Optical switch 1x8 Optical Switches Single mode 1310/1550nm


    Optical Route


    Similar Products


    1x2 optical switch1x4T optical switch1x8T optical switch

    Specifications

    Parameter
    Unit
    OSW-1x8
    Wavelength Range
    nm
    850±40/1300±40
    1260~1650
    Operating Wavelength
    nm
    850/1300
    1310/1550
    Insertion Loss
    dB
    <1.2
    <1.0
    Return Loss
    dB
    MM≥30 SM≥50
    Crosstalk
    dB
    MM≥35 SM≥55
    Polarization Dependent Loss
    dB
    0.05
    WDL
    dB
    ≤0.25
    TDL
    dB
    ≤0.25
    Repeatability
    dB
    ≤±0.02
    Power Supply
    V
    5.0 or 12v
    Lifetime
    times
    ≥107
    Switch Time
    ms
    ≤8
    Optical Power
    mW
    ≤500
    Operating Temperature
    -20~+75 (-40~+85 available)
    Storage Temperature
    -40~+85
    Dimension
    mm
    135×64×32


    Product Overview


    Optical switch 1x8 Optical Switches Single mode 1310/1550nm


    1x8 Multi Channel Optical Switches


    GEZHI 1×8 Multi-Channele Fiber Optical switches is a kind of functional component, with the ability of switching optical route. In optical fiber transmission system, it is used for multi light source/ detector selection, multi-channel fiber monitoring, and ptical fiber path protection etc. Besides, it is also used in optical fiber test system for optical fiber and its component test,outdoor cable test and multi-spot optical sensors monitoring system.



    Features

    Low Insertion Loss
    More Than 128 Channels
    High Stability & Reliability
    Parallel Interface (TTL)
    Modularized Design
    Customzied Wavelength available
